Hydra Tech HT 50 DYS Power Unit
In stock
SKU
Hydra Tech HT 50 DYS Power Unit
₹999,999.00
HT50DYS Portable Hydraulic Power Unit (Tier 4 Final)
Part Number: HT50DYS
The HT50DYS Portable Hydraulic Power Unit is a high-capacity, diesel-powered solution built to drive demanding hydraulic applications with exceptional performance and efficiency. Equipped with a 55 HP Tier 4 Final Yanmar liquid-cooled diesel engine, this power unit offers variable hydraulic output up to 25 GPM at 2800 PSI, making it ideal for powering large pumps, hydraulic tools, and equipment. Its robust design, advanced safety features, and portability make it the perfect choice for industrial, construction, and utility operations.
Key Features:
- Powerful Engine: 55 HP (41 kW) Yanmar diesel engine ensures consistent and reliable performance at 3000 RPM while meeting Tier 4 Final emissions standards.
- High Hydraulic Output: Delivers variable flow rates up to 25 GPM (95 LPM) with a maximum operating pressure of 2800 PSI, supporting a wide range of hydraulic tools and pumps.
- Efficient Cooling and Filtration: Includes a hydraulic oil cooler and 10-micron spin-on return filter with an indicator for clean and efficient operation.
- Large Capacity: Equipped with a 50-gallon hydraulic oil reservoir and a 48-gallon fuel tank for extended runtime and reduced refueling.
- User-Friendly Design: Features variable speed control, a liquid-filled pressure gauge, and fluid level/temperature gauges for easy monitoring and operation.
- Durable and Portable: Built with a skid frame, highway trailer chassis with independent suspension, and a single point lifting bracket for easy transport.
Specifications:
- Hydraulic Output: Variable up to 25 GPM (95 LPM)
- Operating Pressure: Max 2,800 PSI (193 Bar)
- Fuel Tank Capacity: 48 U.S. gallons (182 liters)
- Oil Reservoir Capacity: 50 U.S. gallons (189 liters)
- Fuel Consumption: Approx. 4 gallons/hour (15 liters/hour)
- Hose Port Size: 1" NPT
- Dimensions: 65" H x 62" W x 115" L (166 cm x 158 cm x 292 cm)
- Weight: 1900 lbs. (860 kg)
Applications:
- Drives large pump models such as the S6CSL, S6TC, and S12M.
- Powers hydraulic tools and equipment requiring high flow rates for construction, utility, and industrial operations.
Why Choose the HT50DYS?
The HT50DYS Hydraulic Power Unit combines superior performance, durability, and versatility, making it an essential tool for tackling the toughest hydraulic demands. With its advanced features and reliable design, it ensures efficient operation and extended uptime on any job site.
Contact Intermountain Sales Inc. today to learn more about the HT50DYS Portable Hydraulic Power Unit!
