Compact LX Valve Maintenance Trailer VMT, GAS

In stock

SKU

Compact LX Valve Maintenance Trailer VMT, Gas

₹999,999.00

Compact LX Valve Maintenance Trailer VMT, Gas

Part Number: 79-000-25
As the industry leader in valve maintenance systems, Wachs Utility Products provides a broad range of equipment designed to meet both recommended and mandated procedures. A cost-effective entry point for any valve maintenance program is the Wachs Compact LX Trailer. This trailer features the core component of a successful valve maintenance operation: the industry-leading ERV-750 Extended Reach Valve Operator, offering a 13-foot (3.96-meter) reach and a robust 750 ft/lbs. of torque.

Built for durability and portability, the Compact LX Trailer is ideal for municipalities or contractors seeking an affordable, lightweight, and long-lasting solution. Specifically designed for applications where vacuum excavation or power washout isn’t required, the Compact LX is the perfect platform for operating the ERV-750 with a streamlined, trailer-mounted setup.

Weighing under 1,400 lbs. (635 kg), with a compact footprint of 63 inches (1600 mm) wide and 105 inches (2670 mm) long, the trailer can be easily towed by light-duty vehicles. Its small size makes it particularly well-suited for navigating narrow city streets, tight alleys, fragile terrains, or forested landscapes—anywhere a larger trailer or truck might struggle to fit.

The Compact LX integrates Wachs’ exclusive VITALS software, built with "No Assumptions" logic to prevent valve damage from misdirection or over-torquing. Developed over three decades, VITALS provides mobile and desktop modules to set torque limits and record critical details like valve location, operating direction, and torque applied.

Compact LX Features

16 HP Briggs & Stratton V-Twin gasoline engine
ERV-750 Extended Reach Valve Operator, with a 13-foot (3.96-meter) reach and 750 ft/lbs. of torque
Handheld VITALS controller/datalogger with GPS
HTMA Class II auxiliary hydraulic circuit, rated for 8 GPM @ 1,800 PSI
NATM-compliant trailer
Telescoping valve key

Compact LX Includes
Wachs ERV-750 Extended Reach Valve Operator
Ruggedized TC-100 handheld GPS controller/datalogger
16 HP V-Twin engine with hydraulic pump and fan-cooled heat exchanger for reliable operation
Auxiliary HTMA Class II hydraulic circuit with a 10-gallon (38 L) reservoir, continuous duty rated at 8 GPM (30.3 LPM) @ 1,800 PSI (125 bar)
Telescoping valve key

LX Package Additions
Light bar with arrow board
45-ft (14-meter) auxiliary hydraulic hose reel for powering hydraulic tools
Bluetooth tethering module, pre-installed in the ERV-750, for wireless communication with the controller/datalogger
Steel storage bin

The Wachs Compact LX Trailer is a dependable, cost-efficient, and transportable solution for maintaining valves in the most challenging locations. Whether you’re working in tight urban spaces or fragile landscapes, this system offers all the tools you need to maintain your water infrastructure effectively.

Video:
https://youtu.be/53GdPTfHl-8?feature=shared
